Success Hackintosh macOS Mojave 10.14.6 Build 18G103 in Acer Aspire E5-475G-341S
Specification :
- Processor : Intel® Core™ i3-6006U
- RAM : 8GB DDR4 PC17000 / 2133Mhz
- iGPU : Intel HD Graphics 520
- dGPU : Nvidia GT940MX
- Storage : 1x SSD MidasForce 128GB + 1x SSD V-Gen 256GB
- Ethernet : Realtek RTL8168 Gigabit Ethernet
- Wifi : Atheros QCA9377 and Bluetooth
- USB : Intel Chipset
- Audio Codec : Realtek ALC255
- Touchpad : ELAN ELAN0501 I2C Interface
- Display Size : 14"
- Monitor Resolution : HD 1366 x 768
- Boot Mode : UEFI
- Bootloader : OpenCore r0.9.3
- OS Version : macOS Mojave 10.14.6 Build 18G103
What's Working??
- QE/CI Graphics Of iGPU HD 520
- CPU Power Management
- Restart, Sleep and Shutdown
- Internal Speaker, Headphone audio and Internal Mic
- Brightness
- Brightness Button Up/Down
- Ethernet
- HDMI
- HDMI Audio
- Battery Indicator
- All Port USB and Super Speed Port
- Etc
What's not working??
- NVidia GT940MX (Nvidia Optimus is not supported by Hackintosh)
- Built-In Wifi and Bluetooth (Atheros QCA9377 is not supported by Hackintosh)
- Etc
Keep Hackintosh and Keep Hair Fall !!!
